Double Width Stairway Mobile Scaffold Tower

Double Width Stairway Mobile Scaffold Tower Specification

Color
Silver

Weight
Approx. 120 kg (overall, varies per height)

Technique
Welded construction

Constitute
Aluminum alloy (typical), Steel option available

Sleeve size
48 mm (for tube connections)

Features
Anti-slip stairway design, easy mobility, robust bracing, foldable platform, tool-free assembly

Pin
Spring loaded locking pins

Product Type
Mobile Scaffold Tower

Material
Aluminum Alloy 6061-T6

Components
Stairway Frames, Platforms, Guard Rails, Toe Boards, Outriggers, Bracing, Base Plates, Locking Wheels, Access Ladder

Diameter
48.3 mm

Width
1350 mm (Double Width)

Length
2500 mm (platform length)

Height
Adjustable up to 12 m or as required

Thickness
2.5 mm

Platform Loading Capacity
250 kg per platform

Surface Treatment
Powder Coated / Anodized

Application
Construction, Painting, Maintenance, Industrial Access

Size
Standard double width, platform size 2500 x 1350 mm

Wheel Type
150 mm diameter swivel lockable castors

Outrigger Length
Up to 2.3 m (for high stability)

Compliance
EN 1004 & BS1139 standards

Max Working Height
12.5 m

Ladder Pitch
60 degrees for safe ascent

End Frame Height
2000 mm each section

Guard Rail Height
1000 mm above platform level

Safety Feature
Guard rails at all levels, toe boards, secure stair access

Platform Height Range
1.2 m to 11.5 m

Transport
Modular design for compact transportation

Working Platform Material
Marine plywood with anti-slip coating

Assembly Time
10-20 minutes (depending on height)

Frame Thickness
2.0 mm - 2.5 mm

About Double Width Stairway Mobile Scaffold Tower

Working Height	6 m (20 ft)
Width Type	Double Width
Color	Silver
Brand	Msafe
Platform Length	1.8 m (6 ft)
Load Capacity	200 kg
Access Type	Stairway
Material	Aluminium
Scaffolding Category	Aluminium Scaffolding
Features	Guardrails, Lockable Casters, Toe Boards
Standard Compliance	ISO 9001:2015, EN 1004
Service Duration	1-12 months
Service Mode	Offline
Availability	In Stock

Stairway Tower Repairing Service is designed to maintain and restore the safety, functionality, and reliability of your stairway scaffolding towers.

Enhanced Safety Features

Every level of the tower is equipped with guard rails and toe boards, ensuring worker safety. The 60-degree inclined stairway, 1000 mm high guard rails, and secure stair access help minimize the risk of falls, meeting EN 1004 & BS1139 compliance.

Quick Assembly and Easy Mobility

The stairway scaffold tower can be assembled in just 10-20 minutes, thanks to its modular design and tool-free connections. The 150 mm diameter swivel lockable castors facilitate easy movement, making the tower adaptable for multiple locations on-site.

Sturdy Construction and High Stability

Made with a frame thickness ranging from 2.0 to 2.5 mm and outiggers up to 2.3 m, this tower ensures remarkable stability. The marine plywood platform with anti-slip coating further enhances safety for all kinds of demanding tasks.

FAQ's of Double Width Stairway Mobile Scaffold Tower:

Q: How do I safely assemble the Double Width Stairway Mobile Scaffold Tower?

A: The scaffold tower features a modular design that allows for straightforward assembly, typically taking 10-20 minutes depending on the required height. Ensure all frames and components are securely locked, wheel castors are engaged, guard rails and toe boards are in place at every level, and use outriggers for additional stability at higher elevations.

Q: What safety standards does the scaffold tower comply with?

A: This mobile scaffold tower complies with EN 1004 and BS1139 standards, which govern the safety, design, and structural integrity of mobile access and working towers.

Q: When should the tower's outriggers be deployed for maximum stability?

A: Outriggers, extending up to 2.3 meters, should be used whenever the working height increases or when working on uneven surfaces to provide enhanced stability and prevent tipping.

Q: Where can the Double Width Stairway Mobile Scaffold Tower be transported and set up?

A: Thanks to its modular structure, the scaffold tower can be compactly transported to various job sites and assembled wherever stable ground is available, making it suitable for indoor and outdoor applications.

Q: What materials make the working platform slip-resistant?

A: The working platform is constructed from marine plywood and finished with an anti-slip coating, greatly reducing the risk of slips during wet or dusty working conditions.

Q: How does the stairway design ensure safe access?

A: The integrated stairway features a 60-degree pitch, providing safe, ergonomic ascent and descent. Guard rails at every level and a platform-railing height of 1000 mm offer comprehensive fall protection.

Q: What are the main benefits of using this mobile scaffold tower?

A: Key benefits include rapid assembly, modular transport, enhanced safety features, adjustability across multiple heights, and enduring stability and durability for professional projects.
